ILLUSTRATED PARTS LIST
30 11DEC03 – IP5440-1
Figure 16 MECHANISM AY and LEVERS
Item Part No. Description Quantity Notes
1 221259 LOCATOR - locator lever ay
16 1
2 221065 SPRING
16 1
3 232123 LEVER AY - locator
16 1
4 213526 E-RING
16 3
5 232127 BRACKET AY - auto-focus, 4600, 5600 projectors
16 1
6 250634 SCREW
16 2
7 5B5146 SOLENOID AY - cycle
16 2
8 226047 SPRING - solenoid
16 1
9 166985 SCREW
16
10 128527 E-RING 16 1
11 232125 LEVER AY - cycle, 4200, 4400 projectors
16 1
232125 LEVER AY - cycle, 4600, 5600 projectors
16 1
12 213526 E-RING
16 1
13 232115 SPRING - coil
16 1
14 232124 LEVER AY - half cycle
16 1
15 213526 E-RING
16 1
16 232126 SHAFT
16 1
17 225916 SPRING - shutter lever
16 1
18 221227 LEVER AY - shutter
16 1
19 221220 LEVER AY - drive
16 1
20 230795 LEVER - locator drive
16 1
21 200687 FOLLOWER - drive lever
16 1
22 225915 LEVER - spring indexer
16 1
23 221343 LEVER AY - locator cam
16 1
24 5B5148 ARM/LINK AY - solenoid plunger ay
16 1
