ILLUSTRATED PARTS LIST
32 11DEC03 – IP5440-1
Figure 17 REMOTE CONTROL EC3 for the 5600, 5600-J, 5600-KK PROJECTORS
REMOTE CONTROL EC2 for the 4400 PROJECTOR
Item Part No. Description Quantity Notes
1 5B5271 HOUSING - top remote, EC3, EC2
17 1
2 173718 BUTTON - focus, EC3
17 1
178389 BUTTON - focus, EC2
17 1
3 3H7235 BUTTON - forward/reverse
17 1
4 170750 CONTACT AY - remote EC2, 4400 projector
17 1
184929 CONTACT AY - remote EC3
17 1
5 5B5267 HOUSING - bottom remote
17 1
6 169836 SCREW
17 3
7 170749 CORD - remote, EC2
17 1
184927 CORD - remote, EC3, 5600-KK, 5600-J projectors
17 1
8 185636 LABEL - remote, EC3
17 1 Not visible in graphic.
9 --- REMOTE AY - complete
17 1 Listed in the Kodak
Price Catalog.
10 221478 DIODE - formed
17 1
