ILLUSTRATED PARTS LIST
8 11DEC03 – IP5440-1
Figure 4 LAMP MODULE AY
Item Part No. Description Quantity Notes
1 236541 SCREW
4 1
2 5B5047 PLATE AY - lamp and door
4 1 For the LAMP MODULE AY.
3 259556 SCREW
4 4
4 --- LAMP - ANSI code, FHS
4 1 Listed in the Kodak Price Catalog.
5 259748 TERMINAL AY - lamp socket
4 1
6 628491 LENS - heat absorbing
4 1
7 628305 LENS - condenser
4 1
8 628154 MIRROR - lamp module
4 1
9 235849 EJECTOR - lamp
4 1
10 5B5045 DOOR - lamp module
4 1
11 5B5831 MODULE AY - extra bright, lamp
4 1 Listed in the Kodak Price Catalog.
12 5B5046 LIGHT - door reading
4 1 For the LAMP MODULE AY.
13 239814 SWITCH AY - cycle, with power switch
4 1
14 239813 SPRING - door latch
4 1 Not visible in graphic.
15 628582 LENS - reading light
4 1 Not visible in graphic.
