MDC-2200/2500 Series Chapter 2 Function and control names
0093125002-02 2-3
1 [DAY/NIGHT] key Note: This function is not available for MDC-2200
Change video and background color. 2 types of mode are provided for day and night.
2 [EBL1] key
This key is used to switch on or off EBL1. This key is used to switch operation when EBL2 is
selected and displayed.
3 [EBL2] key
This key is used to switch on or off display of EBL2. This key is used to switch operation
when EBL1 is selected and displayed.
4 [RAIN] knob
This knob is used to adjust to reduce reflection of rain and snow to improve target
delectability. Rain and snow reflection reduction effect is increased by turning knob to the
clockwise direction. It is also used as function key by pressing knob.
5 [SEA] knob
This knob is used to adjust to reduce reflection of ripple of sea surface to improve target
delectability.
Surface reflection reduction effect is increased by turning knob to the clockwise direction. It is
also used as function key by pressing knob.
6 [GAIN] knob
This knob is used to adjust receiving gain to improve target delectability. Gain is increased by
turning knob clockwise. It is also used as function key by pressing knob. It is also used as
function key by pressing knob.
7 [VRM1] key
This key is used to switch on or off VRM1. It is also used to switch operation when VRM2 is
displayed and selected.
8 [VRM2] key
This key is used to switch on or off VRM2. It is also used to switch operation when VRM1 is
displayed and selected.
9 [RANGE] key
The RANGE key changes the range scale. A press of the + key or – key increases or
decreases the range scale, respectively.
10 [ENH] key
Target enhance function is switched by pressing this key, [ENH 1] => [ENH 2] => [ENH 3] =>
Off
