6.9 Generator Reconnection
The generator set can produce a variety of voltages at
either 50 or 60 Hz. See Figure 6-13. This section gives
voltage reconnection instructions. For frequency
adjustments, refer to the generator set service manual,
TP-5867.
Verify that the installation complies with the National
Electrical Code (NEC) and all applicable local and state
codes.
Wires 60 Hz 50 Hz
3* 120/240 110/220
2[
240 220
2[
120 110
* Factory connection
[ Field reconnection
Figure 6-13 Generator Connection Options
6.9.1 Voltage Reconnection
The following information illustrates the reconnection of
4-lead generator sets. Refer to the following connection
schematics. Follow all the safety precautions and
instructions at the beginning of this manual and in this
section while performing the reconnection procedure.
Note: Order voltage reconnection decal 246242 from
an authorized service distributor/dealer and affix
the decal to the generator set after reconnecting
to a voltage different from the nameplate.
Accidental starting.
Can cause severe injury or death.
Disconnect the battery cables before
working on the generator set.
Remove the negative (--) lead first
when disconnecting the battery.
Reconnect the negative (--) lead last
when reconnecting the battery.
WARNING
Disabling the generator set. Accidental starting can
cause severe injury or death. Before working on the
generator set or connected equipment, disable the generator
set as follows: (1) Move the generator set master switch to the
OFF position. (2) Disconnect the power to the battery charger.
(3) Remove the battery cables, negative (--) lead first.
Reconnect the negative (--) lead last when reconnecting the
battery. Follow these precautions to prevent starting of the
generator set by an automatic transfer switch, remote
start/stop switch, or engine start command from a remote
computer.
Hazardous voltage.
Can cause severe injury or death.
Operate the generator set only when
all guards and electrical enclosures
areinplace.
Moving rotor.
WARNING
Grounding electrical equipment. Hazardous voltage can
cause severe injury or death. Electrocution is possible
whenever electricity is present. Open the main circuit
breakers of all power sources before servicing the equipment.
Configure the installation to electrically ground the generator
set, transfer switch, and related equipment and electrical
circuits to comply with applicable codes and standards. Never
contact electrical leads or appliances when standing in water
or on wet ground because these conditions increase t he risk of
electrocution.
Short circuits. Hazardous voltage/current can cause
severe injury or death. Short circuits can cause bodily injury
and/or equipment damage. Do not contact electrical
connections with tools or jewelry while making adjustments or
repairs. Remove all jewelry before servicing the equipment.
