Kohler 14RES

TP-6735 7/17 103Section 7 Wiring Diagrams
Section 7 Wiring Diagrams
Figure 7-3 lists the wiring diagram numbers and page
numbers.
The original design uses the field-connection terminal
block layout shown in Figure 7-1.
GM66565
1
1. Field-connection terminal block (note location of ATS1-4
connections)
2. Connection decal
2
Figure 7-1 Original Field-Connection Terminal Block
The revised design uses the revised fuel system and the
revised field-connection terminal block layout shown in
Figure 7-2.
GM80177
1. Terminal block (note location of ATS1-4 connections)
2. Connection decal
1
2
Figure 7-2 Revised Terminal Block
Wiring Diagram Description
Original Design
(see Figure 7-1)
Revised Design
(see Figure 7-2)
Drawing Number Page Drawing Number Page
Schematic Diagram ADV-7697 104 ADV-8033 105
Point-to-Point Wiring Diagram GM69754 106 GM79591 107
Figure 7-3 Wiring Diagrams and Schematics
