The installer or lifting contractor should choose one of the following methods to lift the generator set depending upon the location
circumstances and the generator set’s weight and size.
Single and Double Spreader Bar and Skid Lifting Bar Method. See Figure 5.
Figure 5 Single and Double Spreader Bar and Skid Lifting Bar Method
Single Spreader Bar and Skid Lifting Bar Method
Double Spreader Bar and Skid Lifting Bar Method
20°
max.
20° max.
20° max.
20° max.
Spreader bar
Lifting bar
Spreader bar
Lifting bar
