Kohler 48RCLC

TP-7203 4/23 63
Reset Calibration
Pressing the select button when “Reset Calibration? Yes” is displayed will discard the changes and reset the calibration to the
original settings. See Figure 44.
Figure 44 Voltage Calibration
Calibrate
To Calibrate Voltage:
1. Press Select when the voltage is
displayed. The voltage flashes.
2. Press the Up or Down arrow button
to change the setting.
3. Press the Select button to save the
setting.
4. Press the down arrow button to
move to the next menu.
Generator - - >
Metering
Volts L1- L2:
240 V
Volts L2- L3:
240 V
Volts L3- L1:
240 V
Frequency:
60.0 Hz
Volts:
240V
Frequency:
60.0 Hz
Reset
Calibration
<- - Return
Reset
Calibration? No
Reset
Calibration? Yes
Calibrate
Calibrate
Calibrate
Note:
Pressing select when Reset Calibration: Yes is displayed will discard the changes and reset the calibration to the original settings.
TP-6811
Three-phase
Single-phase
