Kohler 6VSG Manual

TP-6843 7/15 Section 3 VSC Controller Operation 31
3.9 Overview Menu
Figure 3-10
Figure 3-10 Overview Menu
3.10 Engine Metering Menu
The engine metering menu displays engine status
information as shown in Figure 3-11. This menu
displays status information only. No settings can be
changed from this menu.
Figure 3-11
Figure 3-11 Engine Metering Menu
Overview ---->
1.2 h
Active Alert
(if any)
Genset Status
Standby
Generator: 54V
% Load 73%
Engine: 125F
Oil Pressure: OK
Battery:
13.3V
Engine Runtime:
100.6 h
Date: 02DEC2011
Time: HR:MNpm
Next Exercise:
09:00p 09Dec2011
Next Maintenance:
150 h or Mar2012
SW Version:
4.06
<---- Return
tp6810
Eng Speed:
2300 R/min
Battery:
13.3 V
<---- Return
Engine ---->
Metering
Oil Pressure:
Switch: OK
Oil Temperature:
125 F
