32 Section 3 VSC Controller Operation TP-6843 7/15
3.11 Generator Metering Menu
The generator metering menu displays the generator
voltage and % load. See Figure 3-12.
3.11.1 Calibration
The calibration mode can be entered from the
Generator Metering menu. Contact a
Kohler-authorized distributor/dealer for service.
The Reset Calibration menu allows you to set the
readings back to the default settings after calibration, if
necessary. See Figure 3-12.
Figure 3-12
Figure 3-12 Generator Metering Menu
Hazardous voltage.
Will cause severe injury or death.
This equipment must be installed
and serviced by qualified electrical
personnel.
Generator ---->
Metering
Reset
Calibration
<---- Return
Reset
Calib? No
Volts:
54.0V
Reset
Calib? Yes
Load:
73%
Reset
Calibration
To Next Page
