40 Section 3 VSC Controller Operation TP-6843 7/15
3.16.3 RBUS Information
The RBUS Information menu contains settings for
remote modules that communicate with the VSC
controller using RBUS protocol (see Figure 3-24).
This includes the following optional modules:
Programmable Interface Module (PIM)
Figure 3-24
Figure 3-24 VSC Information Submenu
tp6804
Modules
Connected: 3
Module Timeouts:
1234
Net Cycle Time:
123ms
Module Errors:
1234
< ---- Return
RD
Remote ---->
Devices
See Figure 3-25.
Networking---->
Information
Networking---->
Status
RBUS ---->
Information
<---- Return
Networking---->
Configuration
To Next Page
