TP-6843 7/15 Section 3 VSC Controller Operation 39
3.16.2 Networking Configuration
Submenu (OnCue
®
Password)
The networking Configuration menu includes settings
used for communication with the Kohler
®
OnCue
®
Generator Management System. See Figure 3-24.
For most applications, DHCP is enabled and the IP
settings cannot be changed from the controller
keypad. If DHCP is enabled, IP parameters are not
displayed.
If DHCP is disabled (i.e., if a static IP address is
required), then the IP parameters can be modified.
For applications that require static IP addresses, press
and hold the select button to enable editing, disable
DHCP, and then step to the next parameters and enter
the information.
If an error occurs while setting a parameter, an error
message is displayed and then the controller exits the
edit mode. Previous settings are preserved.
Password
For the initial OnCue
®
setup, you will be required to
reset the OnCue
®
password on the VSC controller,
and then enter it into the OnCue
®
software. To reset
the password, follow the instructions in Figure 3-22.
Note: The password is displayed for only 10 seconds.
Be sure to write down the password and serial
number.
A new password is generated each time the reset
password procedure is performed. If the password is
reset after the OnCue
®
system has been set up, the
connection will be lost. Enter the new password in
OnCue
®
to reconnect.
Figure 3-23
Figure 3-23 Network Configuration Submenu
tp6804
<---- Return
DHCP:
Enabled
Reset OnCue
Password
Reset OnCue
Password? No
S/N: 1234567
New PW: 12345
Press Select to enter YES
or NO as displayed. New
password is displayed for
approximately 10 seconds.
Networking
Configuration
HOLD
Reset OnCue
Password? Yes
UP arrow for YES,
Down arrow for NO.
Networking---->
Information
Networking---->
Status
To Next Page
