Disassembly/Inspection and Service
10162 690 05 Rev. E KohlerEngines.com
Crankcase Components
A
O
B
P
D
E
I
J
K
L
M
N
C
F
G
H
O
M
M
L
N
K
J
I
A
G
F
H
E
C
D
B
P
A Camshaft B Locking Tab* C Regulating Pin* D Governor Gear*
E Cross Shaft* F
Lifter Feed
Gasket Cover
G Lifter Feed Cover H Governor Yoke*
I Crankshaft J
Connecting Rod
End Cap
K Connecting Rod L Piston Pin
M Piston Pin Retainer N Piston O Piston Ring Set P Oil Seal
*Mechanical Governor only.
