Kohler Command PRO EFI Series User Manual

Disassembly/Inspection and Service
96 62 690 05 Rev. EKohlerEngines.com
Cylinder Head Components
C
Q
O
P
R
S
T
U
V
M
X
W
L
N
Z
K
J
I
H
F
G
A
D
E
B
Style B Style A
C
Q
R
S
T
M
W
L
N
K
J
I
H
F
G
A
D
E
B
P
O
Y
A Gasket B Valve C Cylinder Head D Pipe Plug
E Guide Plate F Spacer G Washer H Spark Plug
I Valve Stem Seal J Valve Spring K Valve Spring Retainer L Hydraulic Lifter
M Valve Spring Keeper N Push Rod O Rocker Arm P Rocker Arm Pivots
Q Rocker Stud R Valve Cover Seal S Valve Cover T Grommet
U
Hydraulic Lifter
Style A (Ribbed)
V
Hydraulic Lifter
Style B (Smooth)
W Adjusting Nut X
Adjustable Valve
Train (AVT)
Y Rocker Arm Screw Z
Non-adjustable Valve
Train (Non-AVT)

Kohler Command PRO EFI Series Specifications

General

Fuel System	Electronic Fuel Injection (EFI)
Starter	Electric
Governor Type	Mechanical
Lubrication	Full Pressure
Cooling System	Air Cooled
Ignition System	Electronic
Engine Type	4-cycle, single cylinder, overhead valve (OHV)
