Specifi cations
8
62 690 05 Rev. HKohlerEngines.com
A
L K
O
N
M
J
I
H
G
F
E
D
C
B
A 680.8 mm (26.80 in.) B
93.5 mm (3.68 in.)
Exhaust Port #1
C Oil Pressure Switch D
Engine Mounting
Surface
E 80.2 mm (3.16 in.) F
6.4 mm (0.25 in.)
Square Keyway
G
7/16-20 UNF-2B Inch
38.1 mm (1.50 in.)
Deep
H Ø 28.6 mm (1.13 in.)
I Mounting Hole "A" J
156.2 mm (6.15 in.)
Cylinder #1 Shroud
Removal
K 389.8 mm (15.35 in.) L 423.2 mm (16.66 in.)
M Grass Screen N Cylinder #1 Shroud O
50.0 mm (1.97 in.)
Oil Filter Removal
Engine Dimensions - Starter Side
