Repair Service and Repair Manual
Fuel system
Removal
Fig. 136: Removing electrical contacts
u Remove electrical contacts from injector.
u Disconnect injector cable on both ends.
u Disconnect HT sensor on both ends if installed.
u Remove both adaptors from rocker arm housing.
Fig. 137: Removing high-pressure pipe
u Take off high-pressure pipe 5 from adaptor 9.
124
© 2021 by Kohler Co. All rights reserved.
KD83V16 33525088901_2_1 EN_US
2021-07
