Service and Repair Manual Repair
Charge air system
Fig. 179: Installing clamps
u Pretighten both screws 8 simultaneously to ensure Δ
1
= Δ
2
after tightening.
Information
Bend locking plates 9 after assembly.
u Tighten screws 8 to torque.
u Tighten all screws to torque, making sure that compensators are aligned evenly.
Specific values
Not applicable.
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
157
