Service and Repair Manual Repair
Lubricating system
Removal
u Remove oil line 9.
u Remove return valve 8.
u Remove oil line 13 and screws 12.
u Remove o-ring 10.
u Remove screws 1.
u Remove clamps 2.
u Remove prelubricating pump 3.
u Remove screws 4, distance sleeves 5 and nuts 6.
u Remove holders 7.
Installation
Information
Do not install relay 11 on the engine.
u Install holders 7 with screws 4, distance sleeves 5 and nuts 6.
u Tighten screws 4.
u Hand-tighten prelubricating pump 3 with clamps 2 and screws 1.
u Hand-tighten oil line 13 with screws 12 and o-ring 10.
u Install return valve 8.
u Tighten return valve 8.
u Hand-tighten oil line 9.
u Tighten screws 1.
u Tighten oil lines 9, 12 nuts.
Specific values
Not applicable.
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
199
