Service and Repair Manual Repair

Rocker arms

u Pass flywheel groove index 1.

Step 8

u Stop at flywheel groove index 2.

u Set valve clearance for cylinders A1, A2 and B5, B7. (For more information see: Checking valve

clearance, page 74.) , (For more information see: Setting valve clearance, page 74.)

Step 9

u Pass flywheel groove index 6.

Step 10

u Pass flywheel groove index 3.

Step 11

u Stop at flywheel groove index 4.

u Set valve clearance for cylinders A4, A6 and B1, B3. (For more information see: Checking valve

clearance, page 74.) , (For more information see: Setting valve clearance, page 74.)

Valve set order (alternative method)

Information

There is a marking on the flywheel to set the valve clearance.

The marking may become illegible.

The only possibility is to set by overlap position.

Ignition TDC* A1 B7 A2 B5 A4 B3 A6 B1 A8 B2 A7 B4 A5 B6 A3 B8

Overlap TDC** A8 B2 A7 B4 A5 B6 A3 B8 A1 B7 A2 B5 A4 B3 A6 B1

* Ignition order

** Opposite cylinder (overlap)

Tab. 15: Valve set order

u Set cylinder to overlap TDC position.

u Adjust valve clearance of ignition TDC cylinder.

KD83V16 33525088901_2_1 EN_US

2021-07
