Repair Service and Repair Manual
Rocker arms
u Position seal 10 on cylinder head.
u Insert positioning pins 1 in rocker arm housing.
Fig. 91: Placing tool
Information
Tighten screws from inlet and outlet rocker arms.
u Place tool on pipe.
u Insert pipe into rocker arm housing.
88
© 2021 by Kohler Co. All rights reserved.
KD83V16 33525088901_2_1 EN_US
2021-07
