Service and Repair Manual Repair
Rocker arms
Fig. 92: Installing locking ring
u Secure pipe with locking ring 8.
u Mount rocker arm housing on cylinder head.
Information
Vent cooling system at the end of installation.
Specific values
Not applicable.
Tightening specifications
Refer to standard tightening torques. (For more information see: 5.3 Standard tightening torques,
page 274.)
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
89
