Service and Repair Manual Repair
Cylinder head (SL 224)
Special tool Designation
No illustration Adapter
Tab. 21: Special tools
Consumables and equipment
– Vaseline
– Castrol Optimol paste white T
– Rags
– Cleaner
Overview
Fig. 94: Task overview
1 Cylinder head 5 Flame ring
2 O-ring set 6 Bolt (M30)
3 Seal carrier 7 Washer
4 Cylinder head gasket (soft metal) 8 Locating pin
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
91
