Service and Repair Manual Repair
Cylinder head (SL 224)
u Lubricate bolts 9 with Castrol Optimol paste white T.
u Insert and tighten the bolts.
Information
If cylinder heads are connected with a lifting lug bracket, both need to be taken off and replaced.
Information
Vent coolant circuit at the end of installation.
Specific values
Not applicable.
Tightening specifications
Fig. 101: Cylinder head tightening sequence
Fig. 102: Cylinder head bolts
KD83V16 33525088901_2_1 EN_US
2021-07
© 2021 by Kohler Co. All rights reserved.
95
