Kohler KD83V16

Appendix Operation and Maintenance Manual
Error code
SPN FMI Designation
516345 4 Heating flange 2 - Short circuit to ground low side
516346 5 Heating flange status input 1 - Open circuit
516346 3 Heating flange status input 1 - Short circuit to battery high side
516347 3 Heating flange status input 1 - Short circuit to battery low side
516346 4 Heating flange status input 1 - Short circuit to ground high side
516347 4 Heating flange status input 1 - Short circuit to ground low side
516348 8 Heating flange status input 2 - Open circuit
516348 3 Heating flange status input 2 - Short circuit to battery high side
516349 3 Heating flange status input 2 - Short circuit to battery low side
516348 4 Heating flange status input 2 - Short circuit to ground high side
516349 4 Heating flange status input 2 - Short circuit to ground low side
516187 31 Ignition digital input - Supply voltage out of range
516509 31 Injection data synchronization - Error during measurement of
voltage-based small quantity injection correction
651 0 Injector 1 - Current Rise time too long
651 8 Injector 1 - No current rise time measured
651 5 Injector 1 - Open circuit
651 3 Injector 1 - Short circuit to battery
651 4 Injector 1 - Short circuit to ground
660 0 Injector 10 - Current Rise time too long
660 8 Injector 10 - No current rise time measured
660 5 Injector 10 - Open circuit
660 3 Injector 10 - Short circuit to battery
660 4 Injector 10 - Short circuit to ground
661 0 Injector 11 - Current Rise time too long
661 8 Injector 11 - No current rise time measured
661 5 Injector 11 - Open circuit
661 3 Injector 11 - Short circuit to battery
661 4 Injector 11 - Short circuit to ground
662 0 Injector 12 - Current Rise time too long
662 8 Injector 12 - No current rise time measured
662 5 Injector 12 - Open circuit
662 3 Injector 12 - Short circuit to battery
662 4 Injector 12 - Short circuit to ground
663 0 Injector 13 - Current Rise time too long
663 8 Injector 13 - No current rise time measured
663 5 Injector 13 - Open circuit
663 3 Injector 13 - Short circuit to battery
150
