Kohler KD83V16 User Manual

Appendix Operation and Maintenance Manual
Error code
SPN FMI Designation
516254 11 Volume control valve - PWM signal - Plausibility error
1076 11 Volume control valve - Short circuit load
1076 3 Volume control valve - Short circuit to battery high side
516328 3 Volume control valve - Short circuit to battery low side
1076 4 Volume control valve - Short circuit to ground high side
516329 4 Volume control valve - Short circuit to ground low side
516255 6 Volume control valve 2 - Critical high output current
516255 0 Volume control valve 2 - Critical overcurrent
516255 11 Volume control valve 2 - Critical undercurrent
516256 11 Volume control valve 2 - Current remains above the set point
516257 11 Volume control valve 2 - Current remains below the set point
516336 11 Volume control valve 2 - Electrical error
516255 5 Volume control valve 2 - Open circuit
516258 11 Volume control valve 2 - PWM signal - High limit reached
516259 11 Volume control valve 2 - PWM signal - Plausibility error
516255 11 Volume control valve 2 - Short circuit load
516255 3 Volume control valve 2 - Short circuit to battery high side
516336 3 Volume control valve 2 - Short circuit to battery low side
516255 4 Volume control valve 2 - Short circuit to ground high side
516336 4 Volume control valve 2 - Short circuit to ground low side
5386 6 Wastegate valve - Critical high output current
5386 11 Wastegate valve - Electrical error
5386 5 Wastegate valve - Open circuit
516318 31 Wastegate valve - Short circuit load
5386 3 Wastegate valve - Short circuit to battery high side
516266 3 Wastegate valve - Short circuit to battery low side
5386 4 Wastegate valve - Short circuit to ground high side
516266 4 Wastegate valve - Short circuit to ground low side
97 5 P2264-13 Water in fuel sensor - Open circuit
97 11 Water in fuel sensor - Out of range
97 3 Water in fuel sensor - Short circuit to battery
97 4 Water in fuel sensor - Short circuit to ground
97 31 Water in fuel sensor - Supply voltage out of range
97 0 Water in fuel sensor - Water in fuel detected
6301 5 Water in fuel sensor 2 - Open circuit
6301 11 Water in fuel sensor 2 - Out of range
6301 3 Water in fuel sensor 2 - Short circuit to battery
6301 4 Water in fuel sensor 2 - Short circuit to ground
156
© 2018 by Kohler Co. All rights reserved.
KD83V16 33521030601_0_1 EN_US
2018-07
