Kohler KD83V16 User Manual

Operation and Maintenance Manual Appendix
Error code
SPN FMI Designation
3938 3 Speed adjustment (current) - Short circuit to battery
3938 4 Speed adjustment (current) - Short circuit to ground or open
circuit
3938 31 Speed adjustment (current) - Supply voltage out of range
3938 3 Speed adjustment (voltage) - Short circuit to battery
3938 4 Speed adjustment (voltage) - Short circuit to ground or open
circuit
3938 31 Speed adjustment (voltage) - Supply voltage out of range
677 6 Starter - Critical high output current
677 11 Starter - Electrical error
516342 31 Starter - Locked due to overtemperature
677 5 Starter - Open circuit
677 3 Starter - Short circuit to battery high side
516276 3 Starter - Short circuit to battery low side
677 4 Starter - Short circuit to ground high side
516277 4 Starter - Short circuit to ground low side
516369 6 Starter 2 - Critical high output current
516369 11 Starter 2 - Electrical error
516369 31 Starter 2 - Locked due to overtemperature
516369 5 Starter 2 - Open circuit
516369 3 Starter 2 - Short circuit to battery high side
516370 3 Starter 2 - Short circuit to battery low side
516369 4 Starter 2 - Short circuit to ground high side
516371 4 Starter 2 - Short circuit to ground low side
516424 11 Starter digital input - Starter inhibition due to short circuit
516247 31 Starter digital input - Supply voltage out of range
516425 11 Starter digital input 2 - Starter inhibition due to short circuit
516264 31 Starter digital input 2 - Supply voltage out of range
516511 31 Starters - Not connected in the output 1 to ECU
516512 31 Starters - Not connected in the output 2 to ECU
1076 6 Volume control valve - Critical high output current
1076 0 Volume control valve - Critical overcurrent
1076 1 Volume control valve - Critical undercurrent
516251 11 Volume control valve - Current remains above the set point
516252 11 Volume control valve - Current remains below the set point
516330 11 Volume control valve - Electrical error
1076 5 Volume control valve - Open circuit
516253 11 Volume control valve - PWM signal - High limit reached
KD83V16 33521030601_0_1 EN_US
2018-07
© 2018 by Kohler Co. All rights reserved.
