3
20
MIN
MAX
B
B
Fig. 3.2
Fig. 3.1
A
C
INFORMATION ABOUT USE
EN
3.5 Oil lling
3.3.3 Turning off
1 - Do not turn off the engine when it is running at the maximum rotation speed (except constant speed engine).
2 - Before turning it off, keep it idle at minimum speed for about 1 minute.
3 - Turn the key to OFF position.
3.4 Refuelling
Danger
• Fill the engine off.
• The only approved fuels are those listed in Tab. 1.3 pag. 12.
• In those countries where diesel has a high sulphur content, its is advisable to lubricate the engine with a high alkaline oil or
alternatively to replace the lubricating oil recommended by KOHLER more frequently.
• To avoid explosions or fire outbreaks, do not smoke or use open flames during the operations.
• Fuel vapours are highly toxic.Only carry out the operations outdoors or in a well ventilated place.
• Keep your face well away from the fuel fill to prevent harmful vapours from being inhaled.
• Dispose of fuel in the correct way and do not litter as it is highly polluting.
• When refuelling, it is advisable to use a funnel to prevent fuel from spilling out.The fuel should also be filtered to prevent dust
or dirt from entering the tank.
Do not overll the fuel tank. Leave room for the fuel to expand.
NOTE: At the rst fuelling or if the tank was empty bleeding the fuel system (Par. 5.4 point 8).
1 - Loosen the oil filler cap A or the oil filler cap C if the cap A
is not accessible.
2 - Add the type and amount of oil recommended (Tab. 1.1
and Tab. 1.2).
3 - Before checking oil engine needs to be level.
4 - Remove the oil dipstick B and check that the level is up to
but does not exceed the
MAX
.
5
-
If level is not at the MAX. level, add additional oil.
6 - Re-tighten the cap A or C.
Important
• For safety precautions see Par. 1.4.
UM KDI 1903TCR_2504TCR _ cod. ED0053029490 - 2° ed_rev. 01
