INFORMATION ABOUT REPLACEMENTS
EN
5.2 Oil lter cartridge replacement
1 -
 LoosenthecapA.
2 - RemovethecapAaswellastheoilcartridgeBfromthe
oilfiltersupport.
3 - RemoveandreplacetheoilcartridgeBwithanewone.
 Remove and replace the gaskets C, D and E with new
ones.

Warning
Oil filter cartridge replacement (Par. 5.2) and fuel filter replacement (Par. 5.4)
Incaseoflowusereplaceit12months.
Fordisposalofoilfiltercartridgeandfuelfilterrefer
toPar. 5.6 DISPOSAL and SCRAPPING.
9 - FitandremovetheoildipstickBtocheckthelevel.
 PourinfluiduntilreachingtheMAX levelmark.
10 -Uponcompletion,reinstalltheoildipstickB completely.
11 - TightenthecapAorC.
