6
INFORMATION ABOUT REPLACEMENTS
EN
40
6.3 Fuel filter cartridge replacement
Important
•
Before proceeding with operation, read Par.
3.2.2.
•
Do not fill the new cartridge A with fuel
1.
Procure a suitable container to collect the fuel.
Warning
• In case of low use replace il 12 months.
• To replace the cartridge with Option B filter, it
is necessary to use the ST_55 tool cod.
ED0014604590-S.
• For disposal of oil filter cartridge and fuel filter
refer to Par. 6.5 DISPOSAL and SCRAPPING
Option A
1. Rotate the filter A to take it to the unlocked
position and remove it.
2. Lubricate the gasket C.
3.
Assemble the filter A on the support B and
rotate it until reaches the lock position.
Fig 6.8
