12 TT-1403 4/16
7.3 Operation
7.3.1 Autorun mode
1. Set the time and day and desired switch cycles.
2. Slide set switch to RUN and mode switch to AUTO.
Switching will begin with the next switch-on set
time.
7.3.2 To switch the override ON
Slide mode switch to I. The switch remains on
indefinitely (circuit closed).
Note: Setting the override to ON (I) will signal the
generator set to run continuously.
7.3.3 To switch the override OFF
Slide the mode switch to 0. The switch r emains off
indefinitely (circuit open).
Note: The generator set will not exercise on schedule if
the override is set to OFF (0).
7.3.4 Skip a cycle
In automatic run mode, press the X—> button to skip the
next program.
8 Programming Worksheet
Use the following worksheet to plan on and off switching cycles for each exercise run. Program an off cycle after each
on cycle.
Cycle
On/Off AM/PM h m Day(s)
Ex. 1 On AM 7 20 1--5
Ex. 2 Off AM 7 50 1--5
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
