§3.4 Web UI main interface
After login the Web UI management of K3 IMU by WIFI or USB connection, the main interface
appears with displaying configuration items and positioning. As shown at following figures.
In the Web UI home page, the configuration items are listed at left side. And the positioning
informaiton including coordinates information and satellites are diplayed at right side.
Ref
Component
Description
Status
Positioning information, satellite tracking and the others will
be displayed in this page
Configuration
It contains registration for receiver, base configuration,
antenna configuration, satellite configuration, receiver
configuration and system configuration.
Satellite Information
Display and control the satellites are used or not
Data Record
Configure the parameters for static mode and raw data
download
Data Transfer
Contains NTRIP configuration, TCP/IP configuration and data
transferring with PC
