K3 IMU
Appendix B Technical Terms
Ambiguity: unknown quantity is the integer number of cycles of the carrier phase
measured from the satellite to the receiver.
Baseline: The connection line of the two measurement points, on which to receive
GPS signals and collect observation data simultaneously.
Broadcast ephemeris: message released by the satellite demodulator satellite orbit
parameters.
SNR (Signal-to-noise ratio): an endpoint signal power to noise power ratio.
Cycle skipping: interfere loop skips a few cycles from a balanced point, and stabilize
in the new equilibrium point, this makes the phase integer number of cycles to
generate an error.
Carrier: As the carrier, Frequency, amplitude or phase modulation of the modulated
wave by a known reference value.
C / A code: GPS coarse / acquisition code, modulate the pseudo-random binary code
for the 1023 bit duplex, the bit rate of which is 023MHz, and code repetition period
of 1ms.
Difference measurement: GPS measurements employ cross-satellite cross-receiver
and cross-epoch.
Difference Positioning: the method of determining the relative coordinates between
two or more receiver by tracking the same GPS signal.
Geometric dilution of precision: Describe the contribution of satellite geometry errors
factor in dynamic positioning
Eccentricity:
where a, b of the semi-major axis and semi-minor axis.
Ellipsoid: mathematical graphics formed when an ellipse moves around the minor
axis of rotation in Geodetic Survey.
Ephemeris: the position of celestial bodies over time parameters.
Flattening:
a is the semi-major axis, b is the semi-minor axis, e is the eccentricity.
Geoid: similar to the mean sea level and extends to the mainland special planes.
Geoid everywhere perpendicular to the direction of gravity.
Ionosphere delay: delay of radio waves through the ionosphere (non-uniform
dispersion medium)
