EXPLANATION OF COMPONENTS
MODE SELECTION SWITCH GROUP
Press each mode switch to turn it ON or OFF and to select the mode.
For details of of the setting of the mode to use, see "EFECTIVE USE OF MODE SELECTION SYSTEM (PAGE
3-113)".
It is impossible to use any combination of the lock-up mode and any other mode.
The economy mode and reverse slow mode can be used independently or in combination.
E (1) Lock up mode switch
E (2) Economy mode selector switch
E (3) Reverse slow mode selector switch
Selecting the mode to match the type of work and quality of rock or soil makes it possible to carry out operations
effectively.
¡: Possible to use Ï: Compound use not possible
