V3F25/18 drive
Installation Instruction
© 2004 KONE Corporation AM-11.65.020
All rights reserved. 22 (42) (E) 2004-01-08
5.1.2 Basic LWD setting
Follow this working order exactly. If you forget one step or give wrong values, you have to
restart whole LWD setting.
Step Action On display
Reset the LWD setup.
1 Select
Enable LWD setup (6_74)
parameter.
0 is blinking.
Turn 0 to -1 (minus one). -1 is blinking.
Push ACCEPT. 6_74_0, all digits start to blink.
Push MENU. 6_74
2 Select
Save (6_99) parameter . 0 is blinking.
Turn 0 to 1 and push ACCEPT. 0 turns steady.
Zero load:
3 Select
Enable LWD setup (6_74)
parameter.
0 is blinking.
Push ACCEPT. 6_74_0, all digits start to blink.
Push MENU. 6_74
Half load:
4 Place from 40 % to 60 % of the rated
load in the car.
6_74
Push ACCEPT. 0 is blinking.
Give the load value in kilos (kg). Load value is blinking.
Push ACCEPT. 6_74_0, all digits start to blink.
Push MENU 6_74
5 Select
Save (6_99) parameter . 0 is blinking in the display.
Turn 0 to 1 and press ACCEPT. 0 turns steady.
6 Leave
menu 6 and check that the correct value is recorded by reading the value of
LWD adjustment (5_1) parameter.
7 Check that the LWD information changes when the load is changing.
