Connectors
Topics
TransducerconnectorpinoutJ1,page16
ModemtopsectioninterfaceconnectorpinoutJ3,page17
PowerconnectorJ4,page18
ServiceconnectorJ5,page19
TransducerconnectorpinoutJ1
Thisisthepincongurationforafemaleplug,asseentowardstheplug(faceview).
PinnumberColourSignalMinimum
requirements
1Green
IDdata
0.24mm
2
2Screen
3
Black
TD+
0.5mm
2
4
Blue
TD–
0.5mm
2
5
Green
IDdata
0.24mm
2
6Orange
Ground
0.24mm
2
7
Black
TD+
0.5mm
2
8
Blue
TD–
0.5mm
2
Relatedtopics
InstallingthetransducercablesTD80V,page12
InstallingthetransducercablesTD180,page13
InstallingthetransducercablesTD40VMini,page14
cNODEModemEmbedInstructionManual
