6-7
6.2 Clearing Paper Jams
6.2 Clearing Paper Jams
How to view the animation guide
If a paper jam occurs on this machine, the message [Mishandled paper / Please remove paper following the guide] is
displayed, and the position of the paper jam is displayed on the screen.
Check the paper jam position, then follow the guidance to clear a paper jam.
Do not turn off the main power switch while clearing a paper jam. Otherwise, the trays or conveyance fixing unit
cannot be pulled out.
)[JAM Position] screen
If a paper jam occurs, the [JAM Position] screen is displayed,
and the position of the paper jam is indicated by a number.
- Pressing [Close] changes to the [MACHINE] screen.
- Even while the [MACHINE] screen is being displayed, a
paper jam position is indicated by (red circle).
Pressing [Confirm Details] changes to the [JAM Position]
screen.
To Next Page
