bizhub PRO C1060L

bizhub PRESS C1070/C1070P/C1060/C71hc

5.3 Adjusting the Finisher and Saddle Stitcher

Opening the screen to be adjusted

When the finisher or saddle stitcher is mounted on this machine, you can finely adjust various functions such as fold

positions or staple positions.

Reference

For details about how to adjust the finisher, refer to the HTML User's Guide.

A Press [Adjustment] on the [MACHINE]

screen.

B Press [Finisher Adjustment].
