System Diagram
Accessory Case
CM-A156
Dust Cover
CM-A69
Spectrophotometer
CM-3700A
ACAdapter
AC-A308
USBCables
IF-A21（3m）
USBCables
IF-A22（5m）
White Calibration
Plate CM-A154
(with CD-ROM containing
calibration data and
data-setting software)
Target Mask
CM-A91 (SAV)
Zero Calibration Box
CM-A155
Target Mask
CM-A92 (MAV)
(ø8 mm measurement /
ø11 mm illumination)
Target Mask
CM-A93(LAV)
(ø25.4 mm measurement /
ø30 mm illumination)）
Standard accessories Optional accessories
CM-S100w
Transmittance
SpecimenHolder
CM-A96
CM-A100
Cell
Cell
Professional Edition
Basic Edition
Personal Computer
CM-A130（2mm;setfor100）
CM-A131（10mm;setfor100）
CM-A132（20mm;setfor100）
CM-A97（2mm）
CM-A98（10mm）
CM-A99（20mm）
SpectraMagic
TM
NX
Transmittance
ZeroCalibrationPlate
(3×5 mm measurement /
5×7 mm illumination)
