17
• X-Axis/Y-Axis
Assign Type ......................... [Control Change, No Assign]
This parameter specifies the MIDI messages assigned to the
X-axis and Y-axis of the touchpad.
Control Change
(CC# 0 to 127)
Control change messages will be transmitted. Specify the control
change number to be transmitted.
No Assign No MIDI message will be transmitted.
CC Number ............................................................ [0...127]
This parameter specifies the CC number that will be transmitted
when “Assign Type” has been set to “Control Change”.
Left Value / Lower Value ....................................... [0...127]
This parameter specifies the value of the control change mes-
sage that is transmitted when you touch the left side or bottom
edge of the touchpad.
Right Value / Upper Value .................................... [0...127]
This parameter specifies the value of the control change mes-
sage that is transmitted when you touch the right side or top
edge of the touchpad.
• Touch/Release
In addition to the messages created by moving your finger
across the Touchpad, Control change messages can also be
transmitted when the Touchpad is touched—or released.
Touch Enable .......................................... [Enable, Disable]
This parameter specifies whether to enable or disable touch/
release.
CC Number ............................................................ [0...127]
This parameter specifies the CC number of the control change
message that will be transmitted.
O Value ................................................................ [0...127]
This parameter specifies the value of the control change mes-
sage that is transmitted when you lift your finger from the
Touchpad.
On Value ................................................................ [0...127]
This parameter specifies the value of the control change mes-
sage that is transmitted when you place your finger on the
Touchpad.
