Korg PA 600 User Manual

33
Playing Sounds
Selecting a Sound and playing it on the keyboard
Quick Guide
3 Touch the Upper 1 track’s area in the display, to open the Sound Select window.
Note: You can also open
the Sound Select window by
first touching the track to
which to assign the new
Sound, then pressing the
SOUND button in the SELEC-
TION section .
4 Select a Sound from the Sound Select window, then press the EXIT button to close the
window.
5 Play the Sound on the keyboard.
Note: Selection windows
may automatically close
after a selection. To do this,
uncheck the “Display Hold”
box in the Global > General
Controls > Interface page. In
this case, press the EXIT but-
ton only if you don’t make
any selection but want to
close the window.
i
The selected Sound is highlighted.
Touch a Sound’s name to select it.
Touch one of the side tabs to select a
different Sound bank.
Touch one of the lower tabs to select
a different Sound page.
A Previous and Next Page pair of button may appear
in this area, when more than six pages are available.
As an alternative, repeatedly press the SOUND button
to cycle between the pages.
The currently
selected Sound
appears in the page
header.
Target track for the
selected Sound
Sound bank icon
Sound’s name
Type of Sounds.
The Sound Select win-
dow closes, and the
main screen appears
again, with the selected
Sound assigned to the
Upper 1 track.
i

Korg PA 600 Specifications

General

Polyphony	128 voices
Sequencer	16-track sequencer
Styles	360 factory Styles
Speakers	2 x 15W speakers
Keyboard	61 keys with velocity sensitivity
Dimensions	1030 x 378.3 x 127 mm
User Styles	Up to 1, 200 locations
Amplifier	15W x 2
Audio Inputs	Line In (Left/Right)
Audio Outputs	2 Line Out (Left/Right)
MIDI	In/Out
USB	USB to Host, USB to Device
Connectivity	USB, MIDI, Line In/Out
Sounds	Over 950 (including Stereo Piano and GM Level 2 sounds)
Display	7-inch color TFT touchscreen
Tones	Defined in Sounds as Over 950
