Korg PA 600 User Manual

39
Playing Sounds
Raising or lowering the Upper octave
Quick Guide
Raising or lowering the Upper octave
If all Upper tracks sound too high or too low, you can quickly change which octave they are playing
in.
1 Use the UPPER OCTAVE buttons on the control panel, to transpose all Upper tracks at
the same time.
Note: The Octave Trans-
pose value for each of the
keyboard track is shown
under the Sound’s name.
2 Press both UPPER OCTAVE buttons together to reset the octave to the value saved in
the current Performance.
i
Each time you press this button, the
pitch will be lowered by one octave.
Each time you press this button, the
pitch will be raised by one octave.

Korg PA 600 Specifications

General

Polyphony	128 voices
Sequencer	16-track sequencer
Styles	360 factory Styles
Speakers	2 x 15W speakers
Keyboard	61 keys with velocity sensitivity
Dimensions	1030 x 378.3 x 127 mm
User Styles	Up to 1, 200 locations
Amplifier	15W x 2
Audio Inputs	Line In (Left/Right)
Audio Outputs	2 Line Out (Left/Right)
MIDI	In/Out
USB	USB to Host, USB to Device
Connectivity	USB, MIDI, Line In/Out
Sounds	Over 950 (including Stereo Piano and GM Level 2 sounds)
Display	7-inch color TFT touchscreen
Tones	Defined in Sounds as Over 950
