Korg PA 600 User Manual

32
Playing Sounds
Selecting a Sound and playing it on the keyboard
You can play up to three sounds at the same time on the keyboard. You can also split the keyboard in
two parts, to play up to three sounds with your right hand (Upper), and one with your left hand
(Lower).
Selecting a Sound and playing it on the keyboard
1 Be sure the Upper 1 track is selected and set to play.
Note: Be sure tracks
Upper 2 and Upper 3 are
muted and are not playing. If
you hear more than one
sound, see also page 34 for
how to mute tracks.
2 If you want to play the Sound on the whole keyboard, be sure the keyboard is in Full
Upper mode (i.e., no SPLIT LED turned on). If it is split in two parts, press the SPLIT but-
ton to turn its LED off.
Playing Sounds
Performance section
Split button
Sound Select button
i
A selected track is shown with a white back-
ground. In this example, the Upper 1 track is
selected. If it is not selected, touch it once to
select it.
The fact that there isn’t a
icon over the bank icon means
that the Upper 1 track is set to
play. If it is muted, touch the
bank icon to set it to play.
(Full) Upper

Korg PA 600 Specifications

General

Polyphony	128 voices
Sequencer	16-track sequencer
Styles	360 factory Styles
Speakers	2 x 15W speakers
Keyboard	61 keys with velocity sensitivity
Dimensions	1030 x 378.3 x 127 mm
User Styles	Up to 1, 200 locations
Amplifier	15W x 2
Audio Inputs	Line In (Left/Right)
Audio Outputs	2 Line Out (Left/Right)
MIDI	In/Out
USB	USB to Host, USB to Device
Connectivity	USB, MIDI, Line In/Out
Sounds	Over 950 (including Stereo Piano and GM Level 2 sounds)
Display	7-inch color TFT touchscreen
Tones	Defined in Sounds as Over 950
