Korg PA500 Service Manual

<<Switch, Encoder, Headphones: Display>>
LCD Switch LED
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
ASSIGN SW1
ACCOMP.
MEMORY
MANUAL BASS
EXIT
MENU
STYLE PLAY
SONG PLAY
SEQUENCER
SOUND
GLOBAL
MEDIA
8/16BEAT
POP
BALLAD
BALLROOM
DANCE
ROCK
FUNK&SOUL
JAZZ
STYLE SELECT 1
[ASSIGNABLE SWITCH]
[ACCOMP.]
[MEMORY]
[MANUAL BASS]
[EXIT]
[MENU]
[STYLE PLAY]
[SONG PLAY]
[SEQUENCER]
[SOUND]
[GLOBAL]
[MEDIA]
Dark Gray[8/16BEAT]
Dark Gray [POP]
Dark Gray [BALLAD]
Dark Gray [BALLROOM]
Dark Gray [DANCE]
Dark Gray [ROCK]
Dark Gray [FUNK&SOUL]
Dark Gray [JAZZ]
Dark Gray[STYLE SELECT]
All LEDs light
[ACCOMP.]
[MEMORY]
[MANUAL BASS]
All LEDs light
All LEDs light
[STYLE PLAY]
[SONG PLAY]
[SEQUENCER]
[SOUND]
All LEDs light
All LEDs light
[8/16BEAT]
[POP]
[BALLAD]
[BALLROOM]
[DANCE]
[ROCK]
[FUNK&SOUL]
[JAZZ]
[STYLE SELECT] Upper
Order
Next switch to press
Check Mark
Encoder value
Clockwise(+)
Counter clockwise:(-)
