Korg PA500 Service Manual

1/4
KORG Pa500 Parts List
Part Number
Category
Part Name
Location
Reference
QTY
510300511005
DIGITAL TR
DTC114EUA T106 (S)
KIP-2150
[TOP] Q1
1
510310510502
DOUBLE DIODES
MC2840-T112-1 (S)
KIP-2150
[TOP] D2-4
3
510310511507
DIODE
RLS-73 TE-11 (S)
KIP-2150
[TOP] D5-6 [BOT] D1 D7-9
6
510320511003
OPAMP
NJM4580M-TE1-#ZZZB (S)
KIP-2150
[TOP] IC19
1
510320511009
REGULATOR IC
NJM78L05UA-TE2 (TS)(S)
KIP-2150
[TOP] IC20
1
510320516025
Logic IC
SN74LV14APWR HD74LV14A(S)
KIP-2150
[TOP] IC15
1
510320516029
Logic IC
SN74LV125APWR (S)
KIP-2150
[TOP] IC1
1
510320516083
Logic IC
SN74LVC541APWR
KIP-2150
[TOP] IC5-6
2
510324038010
D/A Converter
AK4384ET-E2
KIP-2150
[TOP] IC21
1
510335510008
CRYSTAL
HC-49US 24.576MHZ SMD (SS)
KIP-2150
[TOP] XT1
1
510345520501
CRYSTAL
MC-306 32.768KHZ 15PF 50PPM
KIP-2150
[TOP] XT3
1
510402511003
EMI/EMC PART
BLM18BD102SN1D (S)
KIP-2150
[TOP] L1-9 L12-14 L17 [BOT] L10-11 L32-33 L35 L42
19
510402511005
EMI/EMC PART
BLM21BD102SN1D (S)
KIP-2150
[TOP] L20-21 L24-25
4
510402511006
Chip INDUCTOR
BLM21PG221SN1D (S)
KIP-2150
[TOP] L18-19 L22-23
4
510450520012
PHONE JACK
PJ-603 (PHONE JACK) (D)
KIP-2150
[TOP] JACK1-2
2
510450520506
DIN JACK
DS-05-02(DIN5P W/OUT SW) (D)
KIP-2150
[TOP] MIDI1-2
2
510474520074
CONNECTOR
JS-1125R-12 (S12B-PH-K-S)
KIP-2150
[TOP] CN7
1
510474520075
CONNECTOR
JS1132R-6 (S6B-EH)
KIP-2150
[TOP] CN10
1
510474527501
USB CONNECTOR
QT-6301-004
KIP-2150
[TOP] CN1
1
510474524004
CONNECTOR
S8B-PH-K / SJ20-08WM (SIDE)(D)
KIP-2150
[TOP] CN8
1
510474527001
FFC CONNECTOR
04FFS-SP-TF(LF)(SN)
KIP-2150
[TOP] CN5
1
500320012320
IC
MB87M4080PB-GE1
KIP-2150
[TOP] IC14
1
500324026017
IC
MC9328MX1DVM20R2
KIP-2150
[TOP] IC13
1
500324006012
SDRAM
V54C365164VEI7(TP)
KIP-2150
[TOP] IC16
1
500324006014
SDRAM
V54C3256164VDI7PC(TP)
KIP-2150
[BOT] IC26
1
500330003700
PHOTO COUPLER
PS9117-F3-A
KIP-2150
[TOP] IC2
1
500320052002
FLASH(NAND)
HY27US08281A-TPCB
KIP-2150
[BOT] IC28
1
500320006072
IC P2ROM
MR27T25603L-DJ2TM03A(X5390H)
KIP-2150
[TOP] IC8
1
500320006073
IC P2ROM
MR27T25603L-DJ3TM03A(X5390L)
KIP-2150
[BOT] IC24
1
500320040125
FLASH(NOR)
MX29LV400TTC-90G (X5390)
KIP-2150
[TOP] IC10
1
510335520019
CRYSTAL
HC-49US/SMD 16MHZ SSM1600000E16F5E
KIP-2150
[TOP] XT2
1
510474526005
CONNECTOR
S11B-PH-K-S(LF)(SN)
KIP-2150
[TOP] CN9
1
510474526006
FFC CONNECTOR
20FLZ-SM2-TB
KIP-2150
[TOP] CN3
1
510402511012
Chip Inductor Network
BLA31AG102SN4D
KIP-2150
[TOP] L26 L40 [BOT] L41
3
510402511013
EMI/EMC PART
NFM21PC105B1C3D
KIP-2150
[TOP] L15-16 L27-28 L39 [BOT] L31 L36-37
8
510320523501
IC
ISP1105W
KIP-2150
[BOT] IC23
1
510474510504
CARD CONNECTOR
AXA263021PKP
KIP-2150
[TOP] SD1
1
510320514038
REGULATOR IC
BA00DD0WHFP-TR
KIP-2150
[TOP] IC18
1
510320514039
RESET IC
BU4327G-TR
KIP-2150
[TOP] IC17
1
510320516093
Logic IC
SN74ALVC08PWR
KIP-2150
[TOP] IC9
1
510320516094
Logic IC
SN74LVC1G02DCKR
KIP-2150
[TOP] IC11
1
510320516095
Logic IC
SN74AHCU04PWR
KIP-2150
[TOP] IC12
1
510320516096
Logic IC
SN74LVC32APWR
KIP-2150
[BOT] IC27
1

Korg PA500 Specifications

General

Type	Arranger Keyboard
Sequencer	16-track sequencer
Weight	10.5 kg
Keyboard	61 keys (velocity sensitive)
Polyphony	80 voices
Sounds	880 sounds + 56 drum kits
Display	Color TFT LCD
Storage	SD card slot
Connectivity	MIDI In/Out
Amplification	2 x 15 Watt
Speakers	2 Speakers
Effects	4 stereo digital multi-effects
