Korg PA500 - Ass.pedal: Assignable Pedal EXP-2; Maximum Level, Frequency Response

Ass.Pedal: Assignable Pedal EXP-2
Reference value and each status
Item Reference1 (big value) Reference2 (small value)
[Slider1:] Max: more than 990 Min:less than 30
[Slider2:] Max: more than 990 Min:less than 30
[Seq Balance] Max: more than 990 Min:less than 30
[JoystickX:] left-right Right end: more than 976 Left end: less than 32
[JoystickX:] Center from l&r Center: 400-564
[JoystickY:] top-bottom Top: more than900 Bottom: less than 200
[JoystickY:] Center from t & b Center: 472-640
[Damper]: DS-1H Return the pedal:728-860 Step on l:less than 223
[Ass Pedal]: EXP-2 Volume Max: more than 928 Volume Min: less than 86
L&r: left and right t&b: top and bottom
<<Maximum Level, Frequency Response>>
This check is measurement of maximum level and frequency response. Push the [START/STOP]
to proceed the check.
[VOLUME] slider: maximum,
Equipment for maximum level : LPF 20kHz, PSOPHO:no ,MODE AC level
Equipment for Freq-Res: LPF: 20KHz, PSOPHO:no ,MODE AC level, PreLPF：OFF(VP-7723B)
Equipment for Freq-Res( Oscillator): +4[dBm] sine-wave 20Hz and 20KHz
Check Channel Reference Level Notice
1 Maximum level 1K[Hz] OUTPUT L/MONO 1.5 - 5.5 [dBm]
2 Maximum level 1K[Hz] OUTPUT R 1.5 - 5.5 [dBm]
3 Freq-Res 20[Hz] OUTPUT L/MONO 1.5 - 5.5 [dBm]
Signal to INPUT L/MONO
4 Freq-Res 20K[Hz] OUTPUT L/MONO 1.0 - 5.0 [dBm]
Signal to INPUT L/MONO
5 Freq-Res 20[Hz] OUTPUT R 1.5 - 5.5 [dBm]
Signal to INPUT R
6 Freq-Res 20K[Hz] OUTPUT R 1.0 - 5.0 [dBm]
Signal to INPUT R
7 Maximum level 1K[Hz] OUTPUT L 3.0 - 7.0 [dBm]
33 OHM load
8 Maximum level 1K[Hz] OUTPUT R 3.0 - 7.0 [dBm]
33 OHM load
