Korg PS60 User Guide

21
Editor operation - Performance mode
1
All performance parameters that can be edited from the PS60 itself can be edited using the
various pages in the editor's performance mode.
Click the PERF mode button, and then click the [Overview] tab of the edit page tabs.
If SPLIT SETTING (located to the left of the panel center in the upper part of the screen)
is set to SUB OFF, the CTRL setting located beside it will automatically be set to MAIN.
The EASY SETUP knobs and timbre selectors in the center of the panel will be assigned
to control the MAIN timbres.
If SPLIT SETTING is set to MAIN LOWER or MAIN UPPER, split is enabled. When
you use the CTRL buttons to switch between MAIN and SUB, the EASY SETUP knobs
and timbre selectors will be assigned to control the respective timbres.
The position of each knob corresponds to the value of the function selected in EASY
SETUP at the right of the knobs.

Korg PS60 Specifications

General

Type	Performance Synthesizer
Synthesis Type	Sample-based synthesis
Velocity Sensitivity	Yes
Aftertouch	No
Arpeggiator	Yes
Sequencer	No
MIDI	In, Out, Thru
Power Supply	DC 9V
Keyboard	61 keys
Sound Engine	EDS-i
Effects	2 Master effects
Controllers	Pitch bend, modulation wheel
Outputs	2 x 1/4" (L/R)
USB	Type B x 1
Sound Generator	EDS-i
Preset Programs	440 programs
Polyphony	120 voices (120 Oscillators)
Inputs	1 x 1/4" (damper)
