Korg PS60 User Guide

2
Installation
Installation in Windows
To install the PS60 Editor and the PS60 Plug-In Editor into Windows XP, Windows Vista, or
Windows 7, proceed as follows.
If you want to connect the PS60 to your computer via USB and use the PS60 Editor and the
PS60 Plug-In Editor, you must install the Korg USB-MIDI Driver. (Refer to the Installation
Guide for details on how to install the Korg USB-MIDI Driver.)
1
Insert the included CD-ROM into your computer’s CD-ROM drive.
Normally the “PS60 Application Installer” will start up automatically.
If your computer is set so the installer does not run automatically, double-click
“KorgSetup.exe” on the CD-ROM.
2
From the list, select the applications that you want to install, and click [Install].
The applications you selected will begin the installation process.
3
4
Follow the on-screen directions to install the desired applications, such as PS60 Editor.
When you’ve finished installing all the selected software, close the installer.
Installing the Korg USB-MIDI Driver
Refer to the Installation Guide for details on how to install the Korg USB-MIDI Driver.

Korg PS60 Specifications

General

Type	Performance Synthesizer
Synthesis Type	Sample-based synthesis
Velocity Sensitivity	Yes
Aftertouch	No
Arpeggiator	Yes
Sequencer	No
MIDI	In, Out, Thru
Power Supply	DC 9V
Keyboard	61 keys
Sound Engine	EDS-i
Effects	2 Master effects
Controllers	Pitch bend, modulation wheel
Outputs	2 x 1/4" (L/R)
USB	Type B x 1
Sound Generator	EDS-i
Preset Programs	440 programs
Polyphony	120 voices (120 Oscillators)
Inputs	1 x 1/4" (damper)
