© 2020 KOSTAL Solar Electric GmbH
Operation and operating the device
Advanced Modbus configuration
Here, further settings can be selected for the Modbus
master functionality. These settings apply to all config-
ured Modbus masters.
Transmit interval
Here, you can set an interval, at which the measure-
ment data is to be transmitted from the KOSTAL Smart
Energy Meter. The Energy Manager usually transmits its
measurement data via the Modbus master as soon as it
is available. If the interval is activated, the data is trans-
mitted at a regular interval instead, regardless of when
it is available. Only the current measuring values at the
transmit time are ever communicated. Mean values are
not produced for the interval.
Parameter Explanation
Activate fixed transmit
interval
Activated
KOSTAL Smart Energy Meter data is
transmitted at a fixed transmit interval.
Selection of interval from pull-down
menu.
Deactivated
KOSTAL Smart Energy Meter data is
transmitted after each measurement
cycle (200ms or 500ms).
Measuring values Current measurement cycle
Current measuring values transmitted
at transmit time.
Mean values for transmit interval
Calculates and transmits a mean
value for all measurement cycles
within the set transmit interval.
