Kramer 105VB User Manual

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your 105A, 1:5 Stereo Audio DA
12
6.2 Technical Specifications
Table 6 includes the technical specifications
1
Table 6: Technical Specifications of the 105A 1:5 Stereo Audio DA
:
INPUT: 1 audio stereo/balanced mono,1Vpp/33k Ω on a 3.5mm mini connector
OUTPUTS: 5 audio stereo/balanced mono 1Vpp/50 Ω on 3.5mm mini connectors
MAX. OUTPUT: 5Vpp (> +4dBu)
AUDIO BANDWIDTH (-3dB): 20kHz
S/N RATIO: 80dB unweighted
CONTROL: Left and right gain rear trimmers (0/+3.5dB range)
COUPLING: AC
THD: 0.03% (2nd harmonic)
POWER SOURCE: 12V DC, 100mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7” x 2.95” x 0.98”) W, D, H
WEIGHT: 0.28kg (0.62lbs) approx.
ACCESSORIES: Power supply, mounting bracket
OPTIONS: RK-3T 19" rack adapters
1 Specifications are subject to change without notice

Kramer 105VB Specifications

General

Brand	Kramer
Model	105VB
Category	Amplifier
Language	English
