FC‑404NET – Protocol 3000 Syntax
12
Protocol 3000 Syntax
With Kramer Protocol 3000 you can control a device from any standard terminal software (for
example, the Windows® HyperTerminal Application) or from UDP clients connected to the
default TCP port 5000 (port numbers can be changed by the user). RS-232/RS-485
communications protocol uses a data rate of 115200 bps, no parity, 8 data bits, and 1 stop bit.
Host Message Format
Start
Address (opt)
Body
Delimiter
#
Destination_id@
Message
CR
Simple Command
Command string with only one command without addressing:
Start
Body
Delimiter
#
Command SP Parameter_1,Parameter_2,…
CR
Command String
Formal syntax with commands concatenation and addressing:
Start
Address
Body
Delimiter
#
Destination_id@
Command_1 Parameter1_1,Parameter1_2,…|
Command_2 Parameter2_1,Parameter2_2,…|
Command_3 Parameter3_1,Parameter3_2,…|
CR
Device Message Format
Start
Address (opt)
Body
Delimiter
~
Sender_id@
Message
CR LF
Device Long Response
Echoing command:
Start
Address (opt)
Body
Delimiter
~
Sender_id@
Command SP [Param1,Param2 …] result
CR LF
CR = Carriage return (ASCII 13 = 0x0D)
LF = Line feed (ASCII 10 = 0x0A)
SP = Space (ASCII 32 = 0x20)
